Description
| Dimensions | 367 x 63 x 41 mm (14.45 x 2.48 x x 1.61″) |
| Weight (Mount Included) | 1.1 kg (2.43 lb) |
| Frequency | |
| AM-5G16-120 | 5.10 – 5.85 GHz |
| AM-5G17-90 | 4.90 – 5.85 GHz |
| Gain | |
| AM-5G16-120 | 15.0 – 16.0 dBi |
| AM-5G17-90 | 16.1 – 17.1 dBi |
| HPOL Beamwidth | |
| AM-5G16-120 | 137° (6 dB) |
| AM-5G17-90 | 72° (6 dB) |
| VPOL Beamwidth | |
| AM-5G16-120 | 118° (6 dB) |
| AM-5G17-90 | 93° (6 dB) |
| Elevation Beamwidth | 8° |
| Electrical Downtilt | 4° |
| Max. VSWR | 1.5:1 |
| Wind Survivability | 200 km/h (125 mph) |
| Wind Loading | 41.7 N @ 200 km/h (9.375 lbf @ 125 mph) |
| Polarization | Dual Linear |
| Cross-Pol Isolation | 22 dB Min. |
| ETSI Specification | EN 302 326 DN2 |
| Mounting | Universal Pole Mount, Rocket Bracket, and Weatherproof RF Jumpers Included |
